Ground
Hog Direct Sales Program
For Fencing and
Landscape Contractors
We are
factory authorized to sell Ground Hog products directly to qualifying
contractors at this discounted price program. All sales made under this
plan are by credit card or check in advance. All prices are Fob San
Bernardino, CA. Complete machines are shipped by motor freight (freight
charges collect). Any augers, accessories, or replacement parts that are
ordered with complete machines will be shipped with that motor freight
shipment unless otherwise specified at the time of the order. Orders for
augers (or accessories or parts only) will be shipped the most economical
way such as UPS Ground, unless otherwise specified. The customer will be
responsible for all freight charges, including any special services
requested (such as UPS Air or FedEx air or other premium services). Prices
listed here are subject to change without notice. Price changes will be
posted as soon as they are available. Prices will be those in effect at
the time of the order. Use the web site order form to place your order.
All orders will be confirmed in writing either by email or regular United
States mail at your request.
Earth Drilling Accessories & Parts
This is just a partial list of replacement parts commonly used. For any service parts not listed here please call for price.
| Part # | Description | Retail | Cost |
| Pengo Teeth | |||
| 35 | Pengo wisdom tooth (standard) | $ 2.10 | $ 1.89 |
| 35-HF | Pengo wisdom tooth (hard faced) | 4.00 | 3.60 |
| 1336 | Pengo wisdom tooth (carbide tipped) | 15.65 | 14.09 |
| 5T-30 | Pengo super tooth | 2.30 | 2.07 |
| 5T-30C | Pengo super tooth (carbide tipped) | 8.50 | 7.65 |
| Standard Blades | |||
| 400 | Cutter blade (for SD4 auger) | $ 3.50 | $ 3.15 |
| 670 | Cutter blade (for SD6 & 7 auger) | 4.40 | 3.96 |
| 800 | Cutter blade (for SD8 auger) | 4.65 | 4.19 |
| 910 | Cutter blade (for SD9 & 10 auger) | 4.95 | 4.46 |
| 912 | Cutter blade (for SD12 auger) | 5.80 | 5.22 |
| Center Pilots | |||
| 100 | Pilot (used on all standard augers) | $ 8.95 | $ 8.06 |
| SB-25 | Pilot (used on all Pengo augers except PSD4) | 13.69 | 12.32 |
| SB-25c | Pilot (optional carbide tipped for Pengo) | 37.00 | 33.30 |
| SB-25cxc | Pilot (optional full carbide for Pengo) | 79.00 | 71.10 |
| SB-35 | Pilot (for larger Pengo series) | 23.50 | 21.15 |
| SB-35c | Pilot (optional carbid tipped for larger Pengo series augers) | 50.00 | 45.00 |
| SB-45 | Pilot (used on PSD4 Pengo auger) | 42.00 | 37.80 |
| 67CS | Weld-on Shank (holds Pengo teeth) - Fits 6" and 7" Pengo augers | 25.70 | 23.13 |
| 8CS | Weld-on Shank (holds Pengo teeth) - Fits 8" Pengo augers | 40.25 | 36.23 |
| 910CS | Weld-on Shank (holds Pengo teeth) - Fits 9" and 10" Pengo augers | 40.55 | 36.50 |
| 12CS | Weld-on Shank (holds Pengo teeth) - Fits 12" Pengo augers | 48.30 | 43.47 |
| 140CS | Weld-on Drive Lug (holds screwbit to Pengo augers) | 14.40 | 12.96 |
| Miscellaneous Parts | |||
| GW12-30 | Centrifugal clutch for models C-71-5 and 1M-5C (also fits T4 trencher) | $ 60.00 | $ 54.00 |
| AX-26 | Drive belt for model C-71-5 | 9.85 | 8.87 |
| 1300 | Clevis Pin with Clip (holds auger to earth drill drive head) | 0.60 | 0.54 |
| 610 | Handle bar rubber grip for model C-71-5 (4 req'd) each: | 3.00 | 2.70 |
| SS2A | Remote stop switch for model C-71-5 | 27.25 | 24.53 |
| SS1 | Remote stop switch for model 1M-5C and T-4 trencher | 13.95 | 12.56 |
Trencher Accessories & Parts
This is just
a partial list of replacement parts commonly used. For any service parts
not listed here please call for price.
NOTE: The 12" depth model uses 18 cutters (whether bullet
tooth or shark tooth). The 18" depth model uses 21 cutters.
There will normally be six (or seven for the 18" depth model) of
each: left, right, and middle (or double) teeth.
| TC-2 | Trencher Carrier - Combined with your trailer hitch to raise & lower easily | $ 335.00 | $ 301.50 |
| 60175 | Carbide Bullet Tooth only (includes the 60176 retaining clip) | 5.40 | 4.86 |
| 60176 | Retaining Clip - Bullet Tooth | 0.20 | 0.18 |
| 60170 | Bit Holder - Right (for bullet tooth) | 5.00 | 4.50 |
| 60171 | Bit Holder - Left (for bullet tooth) | 5.00 | 4.50 |
| 60172 | Bit Holder - Middle (for bullet tooth) | 5.00 | 4.50 |
| 60177 | Shark Tooth - Right | 9.30 | 8.37 |
| 60178 | Shark Tooth - Left | 9.30 | 8.37 |
| 60179 | Shark Tooth - Double (for 3" wide) | 17.50 | 15.75 |
| 60179-4 | Shark Tooth - Double (for 4" wide) | 21.90 | 19.71 |
| 60161A | Driven Sprocket Assy (includes bearing and 2 spiral rings) | 61.50 | 55.35 |
| 60205 | Drive Sprocket | 39.40 | 35.46 |
| 60130 | Digging Chain only (for 12" depth) - (approx. 53" long) less cutters | 94.00 | 84.60 |
| 60131 | Digging Chain only (for 18" depth) - (approx. 63" long) less cutters | 125.00 | 112.50 |
| 60132-S | Digging Chain (12" x 3") complete with Shark cutters mounted | 350.00 | 315.00 |
| 60133-S | Digging Chain (18" x 3") complete with Shark cutters mounted | 407.00 | 366.30 |
| 60130-1 | Master Link (digging chain) | 6.20 | 5.58 |
| 60130-2 | Roller Link (digging chain) | 6.20 | 5.58 |
